IP명 | Power Amplifier with Capless LDO for low harmonic distortion | ||
---|---|---|---|
Category | Analog | Application | transmitter |
실설계면적 | 4㎛ X 4㎛ | 공급 전압 | 3V |
IP유형 | Soft IP | 동작속도 | 5.8GHz |
검증단계 | Simulation | 참여공정 | SS65-2001 |
IP개요 | PA : Class AB-type Power Amplifier for low harmonic distortion LDO : Capless LDO using NCC |
||
- 레이아웃 사진 - |
